HLG Scorpion Diablo Series
Horticulture Lighting Group® (HLG) has been a leader in professional horticulture ligh...
Description for HLG Scorpion Diablo Series
HLG Scorpion® Diablo or HLG Scorpion® Diablo X commercial series lamps are designed for growers who want to maximize crop yields with a grow light that offers high intensity, high efficiency and even coverage. These lamps use 6 advanced design Diablo Quantum Boards® for an even light spread making it perfect for tents, flood tables, rolling benches and vertical racks.
Integrated reflectors improve photon delivery resulting in better quality yields even at the lower levels of canopy. These lamps produce over 2090/2200 PPF output to maximize yields. Available in several Spectrum, Voltage and Power option to help meet your exact needs.
Specifications
| Power Options | 650 Watts, 720 Watts, 750 Watts |
| Input Voltage Options | 120-277VAC or 277-500VAC |
| AC NEMA Plug Options | 5-15, 5-20, 6-15, 6-20, L7-15, L7-20, Pigtails |
| Dimming | 0-10V with standard RJ11 cable |
| Flowering Footprint | 5' x 5' at 15" - 24" |
| Veg Footprint | 6' x 6' at 30” - 36" |
| Dimensions | 38.75" x 36.125" x 3.25" |
| Product Weight | 24.15 lbs |
| Recommended Mounting Height | 15-24 inches above canopy |
| Certifications | UL 8800, UL 1598, CSA, DLC |
Spectrum Options
|
|
Diablo |
Diablo X |
| System PPF Efficacy |
2.90 µmol/J |
3.06 µmol/J |
Features
- Controller compatible with standard RJ11 Cables
- Daisy Chainable on AC side. Limited by breaker size and wire gauge
- Integrated reflectors for increased photon delivery
- High efficiency Full Spectrum White and Deep Red
- Reliable passive-cooled design
- 5 Year Warranty
